Hello all,

Planning to mount 37's on and need some advice.

I want to keep all the stock pull capability. I will be towing at least 6000-6500 lbs 5-6 times a year.

Truck will get 5000 miles a year.

Planning on a lift as well.

Stock Rubicon has 4:10 gears.

I still want to run it on the trails. Medium stuff, I am not planning anything wild.

Question 1. What is the best gearing to put in the axles for the 37's? 4.88 or 5.13?

Question 2. Do I need to take the truck to Jeep and have some reprogramming done? If so, what am I suppose to ask them to do and what can I expect this service to cost?

Thank you in advance.



Advertisement




Carlton

Well-Known Member
Joined
Mar 30, 2019
Messages
207
Reaction score
167
Location
Chicagoland
Vehicle(s)
2019 JLUR
Hello all,

Planning to mount 37's on and need some advice.

I want to keep all the stock pull capability. I will be towing at least 6000-6500 lbs 5-6 times a year.

Truck will get 5000 miles a year.

Planning on a lift as well.

Stock Rubicon has 4:10 gears.

I still want to run it on the trails. Medium stuff, I am not planning anything wild.

Question 1. What is the best gearing to put in the axles for the 37's? 4.88 or 5.13?

Question 2. Do I need to take the truck to Jeep and have some reprogramming done? If so, what am I suppose to ask them to do and what can I expect this service to cost?

Thank you in advance.
If towing often I would stay with the stock set up. However, of you are set on the 37s I'd go 5.13. You can go to the dealership for a reprogramming but I would suggest getting a FlashCal or Tazer. These will allow you or the shop to reprogram for the tires and gears plus added features.


TennesseePA

Well-Known Member
First Name
Mark
Joined
Dec 4, 2017
Messages
844
Reaction score
1,013
Location
Tennessee
Vehicle(s)
2020 Launch Edition, 2008 ES350
Occupation
Physician Assistant
doing a rough calculation to keep the same gear ratio you would need to regear to about 4.56. The math is quite easy (37/33) * 4.1 = 4.59. Now that is just using published tire diameter so it is not 100% accurate but pretty close.


RedTRex

Well-Known Member
First Name
Rick
Joined
Aug 25, 2017
Messages
1,686
Reaction score
1,149
Location
Jacksonville, FL
Vehicle(s)
2013 JKU / 2014 WK2 Diesel
doing a rough calculation to keep the same gear ratio you would need to regear to about 4.56. The math is quite easy (37/33) * 4.1 = 4.59. Now that is just using published tire diameter so it is not 100% accurate but pretty close.
Hey that is pretty nifty calc


beelzebot

Well-Known Member
Joined
Nov 29, 2018
Messages
381
Reaction score
386
Location
Utah
Vehicle(s)
2020 JTR, 2019 Pacifica Hybrid, 2009 Mini Cooper S Convertible
If towing often I would stay with the stock set up. However, of you are set on the 37s I'd go 5.13. You can go to the dealership for a reprogramming but I would suggest getting a FlashCal or Tazer. These will allow you or the shop to reprogram for the tires and gears plus added features.
Agreed on just getting your own programmer. My dealer quoted $125 for all of the recalibrating, but I've seen as high as $250 in some places.


since41

Well-Known Member
Joined
Apr 12, 2019
Messages
171
Reaction score
293
Location
OHIO
Vehicle(s)
Cherokee, Trackhawk, RAM DT,
doing a rough calculation to keep the same gear ratio you would need to regear to about 4.56. The math is quite easy (37/33) * 4.1 = 4.59. Now that is just using published tire diameter so it is not 100% accurate but pretty close.
so if you flip the (33/37) * 4.1 = 3.66
Assuming that is the near gearing when jumping to 37s?

OP

Glad4life

Member
First Name
Tom
Joined
May 10, 2019
Messages
5
Reaction score
4
Location
California
Vehicle(s)
68 fj40, 80 Toyota pickup, 12 Honda covic
  • Thread starter
  • Thread Starter
  • #9
Thanks all for the feedback. 4wheel parts suggested 4:88 gears and they will provide a Speedo recalibrator. Is that what you all are referring too that needs done after changing to 37’s?

Currently in Flagstaff for overland expo west. Big surprise this was happening on my way home.



Ole Cowboy

Well-Known Member
First Name
Don
Joined
May 10, 2019
Messages
446
Reaction score
519
Location
Texas
Vehicle(s)
'19 F 350 King Ranch, 2 John Deeres
Hello all,

Planning to mount 37's on and need some advice.

I want to keep all the stock pull capability. I will be towing at least 6000-6500 lbs 5-6 times a year.

Truck will get 5000 miles a year.

Planning on a lift as well.

Stock Rubicon has 4:10 gears.

I still want to run it on the trails. Medium stuff, I am not planning anything wild.

Question 1. What is the best gearing to put in the axles for the 37's? 4.88 or 5.13?

Question 2. Do I need to take the truck to Jeep and have some reprogramming done? If so, what am I suppose to ask them to do and what can I expect this service to cost?

Thank you in advance.
If you are wanting 37's then go with 4:88's. 5:13 are getting a bit on the steep side and even with 37's you are going to be spinning some rpm on the highway. 4:88 should keep you inside the cooling envelope of your JT, its also one of the strongest gearsets so it will take the street, miles and off road without issue. Jeep has beefed-up that D 44 axle set and if you keep your tires balanced and rotated you should see good life out the upgrade.

TIP: Big jump in tire size, so it begs the question: How much air pressure do I run? First, every tire is different, when I ran BFG KM2's I ran 16 psi so how did I arrive at that? Find an empty parking lot with a puddle of water or a dusty road you can pull off on.

Tires are all about 1 thing, the Contact Patch and they are meant to have a full contact patch or you can wear out the center of the tire (too much air), wear out the outer edges (not enough air), your air pressure needs to be set at Goldilocks, not too much, not too little.

Drive-thru water onto dry pavement and look at the tracks, it will show the contact patch adjust air pressure till you go Goldilocks. Drive onto a dusty road and stop, look at the dust on the tire another way of seeing what your contact patch looks like. It may take several outing to find it.

Door jamb air pressure is based upon the OEM tire and F/R weight of the vehicle, change the size of the tire and you must change the AP. REMEMBER: The Tire does NOT care what AP you run as long as it gets it's happy contact patch.

FYI . Where did I get this info. Growing up on the ranch we had a lot of rolling vehicles. I learned from my dad, that is how it was done back in his day, tire pressure gages were few and very far inbetween, $$$ to boot and inaccurate.

To this day every time I drife thru water or dust when I stop I look at my tires and contact patch...


homerun

Well-Known Member
Joined
Oct 30, 2017
Messages
878
Reaction score
1,053
Location
Fort Collins, Colorado
Vehicle(s)
1996 XJ, 2004 Ford Ranger, 2013 Subaru Impreza, 1996 HD Springer Softtail, past jeep 1995 YJ
If you are wanting 37's then go with 4:88's. 5:13 are getting a bit on the steep side and even with 37's you are going to be spinning some rpm on the highway. 4:88 should keep you inside the cooling envelope of your JT, its also one of the strongest gearsets so it will take the street, miles and off road without issue. Jeep has beefed-up that D 44 axle set and if you keep your tires balanced and rotated you should see good life out the upgrade.

TIP: Big jump in tire size, so it begs the question: How much air pressure do I run? First, every tire is different, when I ran BFG KM2's I ran 16 psi so how did I arrive at that? Find an empty parking lot with a puddle of water or a dusty road you can pull off on.

Tires are all about 1 thing, the Contact Patch and they are meant to have a full contact patch or you can wear out the center of the tire (too much air), wear out the outer edges (not enough air), your air pressure needs to be set at Goldilocks, not too much, not too little.

Drive-thru water onto dry pavement and look at the tracks, it will show the contact patch adjust air pressure till you go Goldilocks. Drive onto a dusty road and stop, look at the dust on the tire another way of seeing what your contact patch looks like. It may take several outing to find it.

Door jamb air pressure is based upon the OEM tire and F/R weight of the vehicle, change the size of the tire and you must change the AP. REMEMBER: The Tire does NOT care what AP you run as long as it gets it's happy contact patch.

FYI . Where did I get this info. Growing up on the ranch we had a lot of rolling vehicles. I learned from my dad, that is how it was done back in his day, tire pressure gages were few and very far inbetween, $$$ to boot and inaccurate.

To this day every time I drife thru water or dust when I stop I look at my tires and contact patch...
Chalk works just as easily.
