I don't understand your question. (To clarify I was referring to the Wrangler Rubicon). When properly equipped with a 3.6 Pentastar with automatic it has a tow rating of 5k.
Respectfully, you’re not understanding the question. He’s not saying Jeep doesn’t “rate” the Wrangler to tow 5K, he’s saying that while Jeep rates Wrangler to tow 5K with the tow package the hitch they install on the vehicle isn’t rated to tow 5K. Defeats the purpose of rating it to tow 5K when you only install a hitch that can only handle 3500 lbs.
Sponsored



Slojo

Well-Known Member
First Name
Donald
Joined
Dec 11, 2017
Threads
4
Messages
381
Reaction score
362
Location
Ft Myers
Vehicle(s)
2008 JK Unlimited X, 2011 Grand Cherokee, 2016 Colorado Z 71
Respectfully, you’re not understanding the question. He’s not saying Jeep doesn’t “rate” the Wrangler to tow 5K, he’s saying that while Jeep rates Wrangler to tow 5K with the tow package the hitch they install on the vehicle isn’t rated to tow 5K. Defeats the purpose of rating it to tow 5K when you only install a hitch that can only handle 3500 lbs.
Ok, I get the Class II / III hitch thing. Even with all of the notes and asterisks, Jeep is opening itself up to trouble over a simple cheap upgrade.


DanW

Well-Known Member
First Name
Dan
Joined
Mar 2, 2017
Threads
34
Messages
1,378
Reaction score
1,674
Location
Brownsburg, Indiana
Vehicle(s)
21 JT Rubi, 18 JLU Rubi, 2008 JKU Rubi, 07 Vette
I don't understand your question. (To clarify I was referring to the Wrangler Rubicon). When properly equipped with a 3.6 Pentastar with automatic it has a tow rating of 5k.
I think you'd have to get free floating rear axles for that. Without that, I've never seen a Wrangler rated at more than 3500.


Zachanadandy

Well-Known Member
First Name
Zach
Joined
Oct 17, 2023
Threads
3
Messages
1,160
Reaction score
1,683
Location
Patterson, ca
Vehicle(s)
2023 gladiator Mojave
Occupation
Electrical foreman
I think you'd have to get free floating rear axles for that. Without that, I've never seen a Wrangler rated at more than 3500.
But even the ones with the full float axle come with a hitch rated at 3500lbs. I can't find an aftermarket class 3 hitch for the Wrangler. In my opinion it was nothing but a marketing campaign as you cannot at this point "properly equip" a JLU to tow 5k. Definitely not from the factory and even aftermarket doesn't look readily available.


Iam_Gladiator

Active Member
First Name
Stevens
Joined
Jul 4, 2023
Threads
0
Messages
35
Reaction score
21
Location
New Mexico
Vehicle(s)
Infiniti QX30
The Wrangler doesn't come with a 5k lb tow rating. They claimed it would be available for 2024, but there is not 1 example that has actually come with a hitch rated over 3500lbs. Not saying that has any relevance to gladiator 4xe tow ratings, but it's a myth that the 4xe JLU is rated lower than the non 4xe.
Only on models that have full float rear axle. Those are not available on 4xe-models.


Sponsored

Zachanadandy

Well-Known Member
First Name
Zach
Joined
Oct 17, 2023
Threads
3
Messages
1,160
Reaction score
1,683
Location
Patterson, ca
Vehicle(s)
2023 gladiator Mojave
Occupation
Electrical foreman
Only on models that have full float rear axle. Those are not available on 4xe-models.
Again only slower, even the Rubicons with the full float axle come with a 3500lb rated hitch. Jeep doesn't make, provide, or install a Wrangler hitch rated over 3500lbs on ANY model so tell me how you're going to tow 5k? The 4xe gets the same 3500lb hitch, ie every JLU is in fact rated to tow the same.


Bobzdar

Well-Known Member
Joined
Apr 3, 2019
Threads
7
Messages
516
Reaction score
630
Location
Richmond
Vehicle(s)
2020 Gladiator Rubicon, 1989 grand wagoneer
I'm guessing the answer is no, but I'm curious what folks think about the possibility of the Gladiator 4xE being offered with the Max Tow package and a 6500lb tow rating. That would match what the diesel platform provided without a Max tow package. On the Wrangler the standard tow capacity is 5000lbs with either the V6 or 2.0 Turbo with the 4xE version coming in at 3500lbs with the 2.0.
Having a Wrangler 4xe, everything is the same as the 5000lbs rated Wrangler versions but the limitation is cooling, so I don't really see how they can get the gladiator to 6000lbs plus towing given that limitation. I hope they do, I'll buy one

I've towed 5000lbs with my 4xe and had to slow down some on really big hills in 80 degree plus weather due to heat. On the mass tpk there's a stretch that goes from 200' elevation to 1700' in a straight climb and on an 85 degree day I had to gradually slow from 65mph to 55mph to keep the engine temps under 240. That was the only limitation, otherwise it has tons of power and no stability issues. Trans never got over 205 degrees, battery power never got reduced. It's purely cooling limited. 9mpg average on a 2k mile trip towing a 5000lbs loaded camper from VA up into Canada and back in July.

OP
OP

kltk1

Well-Known Member
Joined
Dec 19, 2017
Threads
5
Messages
47
Reaction score
23
Location
NJ
Vehicle(s)
2016 RAM 1500
That’s interesting. Thank you. I wonder if having a 4.10 gear ratio would have effected the driving experience while towing that much weight.


Bobzdar

Well-Known Member
Joined
Apr 3, 2019
Threads
7
Messages
516
Reaction score
630
Location
Richmond
Vehicle(s)
2020 Gladiator Rubicon, 1989 grand wagoneer
Only on models that have full float rear axle. Those are not available on 4xe-models.
The Rubicons all get the full float axles. The 4xe and 392 don't have enough cooling to pull 5000lbs. Everything else is the same, but the 392 gets a small lift, 35's and 4.56 gears. Cooling is also the limitation with the gladiator.


Sponsored

RJinPV

Well-Known Member
First Name
Roger
Joined
Jul 19, 2022
Threads
6
Messages
309
Reaction score
391
Location
Southern Cal
Vehicle(s)
2023 JT Rubicon, 2017 Grand Cherokee Trailhawk
Occupation
Retired
I’d look to the Grand Cherokee 4xe tow rating as a clue. With the tow package the GC 4xe is rated at 6000lbs. That’s what I remember when I was looking at the GC owners manual for the 2024 model year a while ago. The Gladiator might be a bit heavier and the grill may be a limiting factor for cooling compared to the GC. Therefore, I would be surprised if the Gladiator 4xe would tow more than 6000lbs


Iam_Gladiator

Active Member
First Name
Stevens
Joined
Jul 4, 2023
Threads
0
Messages
35
Reaction score
21
Location
New Mexico
Vehicle(s)
Infiniti QX30
Not sure if you’re being sarcastic in your response to the above two posts, but my answer to your topic is No.

No 4XE Gladiator with Max Tow. You’ll have to wait for a full EV Gladiator for that.
I think you might be right, I recall one of the videos from either TFL or another YouTube channel that discussed how the hybrid engine design in the Wrangler would not be suitable for towing in the Gladiator and probably the reason why we haven’t seen a 4xe variant yet.


ShadowsPapa

Well-Known Member
First Name
Bill
Joined
Oct 12, 2019
Threads
190
Messages
31,397
Reaction score
38,384
Location
Runnells, Iowa
Vehicle(s)
'22 JTO, '23 JLU, '82 SX4, '73 P. Cardin Javelin
Occupation
Retired auto mechanic, frmr gov't ntwrk security admin
Vehicle Showcase
3
Having a Wrangler 4xe, everything is the same as the 5000lbs rated Wrangler versions but the limitation is cooling, so I don't really see how they can get the gladiator to 6000lbs plus towing given that limitation. I hope they do, I'll buy one
No, it's not the same......... the rear axle is different.

I've towed 5000lbs with my 4xe and had to slow down some on really big hills in 80 degree plus weather due to heat. On the mass tpk there's a stretch that goes from 200' elevation to 1700' in a straight climb and on an 85 degree day I had to gradually slow from 65mph to 55mph to keep the engine temps under 240. That was the only limitation, otherwise it has tons of power and no stability issues. Trans never got over 205 degrees, battery power never got reduced. It's purely cooling limited. 9mpg average on a 2k mile trip towing a 5000lbs loaded camper from VA up into Canada and back in July.
You'll only tow a load with the engine running. We've discussed this to death on the dedicated 4xe forums. The electric motors on these can't handle a sustained load at highway speeds and will kick the engine on to reduce the load and amperage draw on the electric motor. Otherwise, even just driving in hot weather that engine may kick in now and then to reduce the load - and temperature - of the electric motor sitting in the front of the transmission.

Imagine that sort of a load on a 2.0 turbo and that sort of heat - 240 degrees, that oil has to be suffering.
That's not a Wrangler I'd want to buy used.


I’d look to the Grand Cherokee 4xe tow rating as a clue. With the tow package the GC 4xe is rated at 6000lbs. That’s what I remember when I was looking at the GC owners manual for the 2024 model year a while ago. The Gladiator might be a bit heavier and the grill may be a limiting factor for cooling compared to the GC. Therefore, I would be surprised if the Gladiator 4xe would tow more than 6000lbs
Apples and oranges. You have the drag of a Wrangler vs. the drag of a Grand Cherokee at highway speeds, cooling and other factors.
The Grand Cherokee with 3.6 has a tow rating of 6,200 pounds - more than some of the Gladiators! What's that tell you?
It's not all as simple as people seem to keep circling back to.
If a 2021 Grand Cherokee with 3.6 and 8 speed auto can tow more than a Gladiator with the 3.6 and 8 speed auto, there's far more to it than people here are grasping.


Bobzdar

Well-Known Member
Joined
Apr 3, 2019
Threads
7
Messages
516
Reaction score
630
Location
Richmond
Vehicle(s)
2020 Gladiator Rubicon, 1989 grand wagoneer
No, it's not the same......... the rear axle is different.


You'll only tow a load with the engine running. We've discussed this to death on the dedicated 4xe forums. The electric motors on these can't handle a sustained load at highway speeds and will kick the engine on to reduce the load and amperage draw on the electric motor. Otherwise, even just driving in hot weather that engine may kick in now and then to reduce the load - and temperature - of the electric motor sitting in the front of the transmission.

Imagine that sort of a load on a 2.0 turbo and that sort of heat - 240 degrees, that oil has to be suffering.
That's not a Wrangler I'd want to buy used.




Apples and oranges. You have the drag of a Wrangler vs. the drag of a Grand Cherokee at highway speeds, cooling and other factors.
The Grand Cherokee with 3.6 has a tow rating of 6,200 pounds - more than some of the Gladiators! What's that tell you?
It's not all as simple as people seem to keep circling back to.
If a 2021 Grand Cherokee with 3.6 and 8 speed auto can tow more than a Gladiator with the 3.6 and 8 speed auto, there's far more to it than people here are grasping.
What? Of course the engine is running, but it gets hot. I didn't get reduced battery power but had to slow to keep the (gas) engine under 240.

The '24 Rubicon 4xe has the full float rear axle. https://s3.amazonaws.com/chryslermedia.iconicweb.com/mediasite/specs/2024_JP_Wrangler_4xe_SP.pdf

Notice where it says rear axle: Dana 44 hd full float (Rubicon 4xe).

Prior to '24 doesn't. The 392 and 4xe have reduced towing because they are cooling limited. It's a bummer because the 4xe drivetrain is excellent for towing, lots of low end torque. It works well and does not cut power. I think this is why the gladiator 4xe has been delayed for so long, they are trying to get the cooling to where it's not severely limited in towing. I don't have high hopes tbh.


RJinPV

Well-Known Member
First Name
Roger
Joined
Jul 19, 2022
Threads
6
Messages
309
Reaction score
391
Location
Southern Cal
Vehicle(s)
2023 JT Rubicon, 2017 Grand Cherokee Trailhawk
Occupation
Retired
Apples and oranges. You have the drag of a Wrangler vs. the drag of a Grand Cherokee at highway speeds, cooling and other factors.
The Grand Cherokee with 3.6 has a tow rating of 6,200 pounds - more than some of the Gladiators! What's that tell you?
It's not all as simple as people seem to keep circling back to.
If a 2021 Grand Cherokee with 3.6 and 8 speed auto can tow more than a Gladiator with the 3.6 and 8 speed auto, there's far more to it than people here are grasping.
Yup, There are differences between the GC and the JT. The ones I mentioned plus the ones you mentioned, plus curb weight, unibody versus cab on chassis, braking capability and others. However, I still think the GC 4XE gives us the best clue. If we look at it a bit differently and compare the GC with a 3.6 pentastar and the GC 4Xe we see the 4Xe gives up a few hundred pounds of towing capacity. Therefore, the same JT 4Xe penalty compared to a JT 3.6L may be a few hundred pounds. Then a JTR 4XE towing could be 6500 to 6800lbs. And if they make a JT 4Xe Max Tow trim then maybe they could get towing both of 7000 lbs. I'm just pessimistic because I've lost faith in Stelantis management
