Offset and Backspacing to not have wheels/tires stick outside of fenders.

armaunr

Member
First Name
Armaun
Joined
Aug 22, 2020
Messages
7
Reaction score
0
Location
USA
Vehicle(s)
Jeep Gladiator
I want to run a 2-2.5inch lift and 35 inch tires. What kind of offset and backspacing should i look for?

Edit: sorry forgot to say this in the post but I dont want the tires/wheels to stick out of fender. Thanks!



Advertisement




Last edited:

Renegade

Well-Known Member
First Name
Zac
Joined
Sep 11, 2017
Messages
1,931
Reaction score
2,295
Location
Signal Mountain, TN
Vehicle(s)
2020 JT
Stock wheels are +44. You can finals several wheels in +30, which would be a nice one to keep them looking conservative.


bastage

Well-Known Member
Joined
Apr 8, 2020
Messages
988
Reaction score
770
Location
Idaho
Vehicle(s)
2020 Gladiator Sport S w/ Max Tow
Vehicle Showcase
1
AEV Borah JL spec are +25 offset. I think AEV has several wheels that are about the same.



Phljeeper

Well-Known Member
First Name
Paul
Joined
Jul 31, 2016
Messages
408
Reaction score
329
Location
West Chester, PA
Vehicle(s)
2020 Jeep Gladiator Rubicon
Vehicle Showcase
1
You can run stock wheels if you like them. No spacer needed for 35s or 37s. Just a minor steering stop adjustment by adding a washer.

OP

armaunr

Member
First Name
Armaun
Joined
Aug 22, 2020
Messages
7
Reaction score
0
Location
USA
Vehicle(s)
Jeep Gladiator
  • Thread starter
  • Thread Starter
  • #5
You can run stock wheels if you like them. No spacer needed for 35s or 37s. Just a minor steering stop adjustment by adding a washer.
on a sport? Will there be rubbing?


bastage

Well-Known Member
Joined
Apr 8, 2020
Messages
988
Reaction score
770
Location
Idaho
Vehicle(s)
2020 Gladiator Sport S w/ Max Tow
Vehicle Showcase
1
on a sport? Will there be rubbing?
On a regular sport with the narrow axles you may want to stock to a fairly narrow tire. The Kenda Klevar 35x10.50r17 is about perfect for this.

OP

armaunr

Member
First Name
Armaun
Joined
Aug 22, 2020
Messages
7
Reaction score
0
Location
USA
Vehicle(s)
Jeep Gladiator
  • Thread starter
  • Thread Starter
  • #7
On a regular sport with the narrow axles you may want to stock to a fairly narrow tire. The Kenda Klevar 35x10.50r17 is about perfect for this.
okay, cool thanks. Do you think the milestar patagonia a/t r will fit? I'm not exactly sure what the "10.50r17" part means, but if there is another tire with that spec will it also fit?


bastage

Well-Known Member
Joined
Apr 8, 2020
Messages
988
Reaction score
770
Location
Idaho
Vehicle(s)
2020 Gladiator Sport S w/ Max Tow
Vehicle Showcase
1
okay, cool thanks. Do you think the milestar patagonia a/t r will fit? I'm not exactly sure what the "10.50r17" part means, but if there is another tire with that spec will it also fit?
35x10.50r17 is 35" tall x 10.50" wide with a 17" wheel. The Kenda's are kind of a unicorn in that they are 10.5" wide instead of the more common 12.5" wide. With an inch on either side it means you have an extra inch of clearance before you hit anything when you turn. PLENTY of folks are running the 12.5" wide 35" tires. There are a bunch on stock wheels so you would probably be fine. Going to the narrower tire or a wheel with less positive offset just add's clearance.

Milestar's 35" tires are 12.50 wide. You can always just buy the tires you want & mount them. If you have issues add wheel spacers bringing everything out a bit.


Membrain

Well-Known Member
First Name
Dirk
Joined
Mar 7, 2020
Messages
157
Reaction score
78
Location
DFW TX
Vehicle(s)
2014 JKURX & 2020 JTR
Build Thread
Link
Check the lift manufacturer's specifications on wheel and tire fitments.


MainePure

Member
Joined
Sep 14, 2020
Messages
8
Reaction score
5
Location
Maine
Vehicle(s)
2021 Gladiator Sport
I found some of the Icon wheels have +25 offset in a 17" wheel. That's what I'm going to go with.


Bacon

Well-Known Member
First Name
Mike
Joined
Oct 28, 2019
Messages
149
Reaction score
171
Location
North NJ
Vehicle(s)
JTR-LE
My AEV Savegre IIs don’t stick out. I like the tires nice and tucked under the flares.

17x8.5 with 5.77in backspacing (+25mm offset)


BrightWhiteGladiator

Well-Known Member
First Name
Andrew
Joined
Aug 8, 2020
Messages
191
Reaction score
100
Location
Indianapolis
Vehicle(s)
2020 Jeep Gladiator Overland
Build Thread
Link
Occupation
Marketing - Planning & Research
It will differ for literally every wheel based on server also permutations: offset, backspacing, width, tire size, etc. Your best bet is to use a site like below to input current and prospective wheel info and see what it tells you the difference will be. I did this with mine and what the website told me was dead nuts accurate.

https://www.rimsntires.com/specspro.jsp
