I've included some of these pics in other posts, but I'll get into more detail of what I did because, well this is a DIY write-up section!!
Here's what I'll disucss:
Decals:
Painted Tow Hooks:
I love the red tow hooks on the Rubicon and wanted to do something similar.
It was a simple process of covering the truck, taping around the hooks, giving it a brief sanding with 220, then two coats of Rustoleum Gloss Deep Blue. Turned out like factory-made!
Stubby Antenna:
I bought the following antenna on Amazon and painted it with the same tow hook paint.
https://www.amazon.com/gp/product/B07KY6PK7G
Window Tinting:
I bought a 10' roll of 20% VLT on Ebay. I tinted the front door windows to match the rear. I also put the same tint on the rear window. IMO the rear wasn't dark enough because I felt like people could easily see into the cab because that window is much closer in a truck. I really wanted to tint the windshield but it's not worth risking the ticket from the law
Phone Charger/Holder:
I give credit for the idea to @Aarorei.
My phone fits perfectly in the key fob holder, so I 3D printed a device to mount in the slot, then ran a USB-C cable through that. Simple plug and play from now one!
I do the 3D design using Autodesk Fusion 360. It's a professional design software tool and is free for hobbyist use.
I use Cura for slicing the 3D models and print them on a Monoprice MP Select Mini v2 printer. It's a great inexpensive printer that I've been using for years.
4x8 Support rails:
Nothing too special here. I just wanted these to look good so I painted the supports to match the bed.
The rear 2x4's are screwed together and tapered at the bottom for a tight fit in the bed. What I've grown to like with these is that they compartmentalize the bed so I can put groceries, etc in the back so they don't fly around everywhere!
Here's what I'll disucss:
- Custom decals
- Painted tow hooks
- Stubby Antenna
- Tinted windows
- Key fob slot phone charger holder
- 4x8 support rails
Decals:
- I use Silhouette Studio and the Silhouette Cameo 3 vinyl cutter to design and create all my custom decals.
- The vinyl I use is Oracal 651 which is a outdoor grade vinyl. The colors I used are Traffic Blue and Matte Black.
Painted Tow Hooks:
I love the red tow hooks on the Rubicon and wanted to do something similar.
It was a simple process of covering the truck, taping around the hooks, giving it a brief sanding with 220, then two coats of Rustoleum Gloss Deep Blue. Turned out like factory-made!
Stubby Antenna:
I bought the following antenna on Amazon and painted it with the same tow hook paint.
https://www.amazon.com/gp/product/B07KY6PK7G
Window Tinting:
I bought a 10' roll of 20% VLT on Ebay. I tinted the front door windows to match the rear. I also put the same tint on the rear window. IMO the rear wasn't dark enough because I felt like people could easily see into the cab because that window is much closer in a truck. I really wanted to tint the windshield but it's not worth risking the ticket from the law
Phone Charger/Holder:
I give credit for the idea to @Aarorei.
My phone fits perfectly in the key fob holder, so I 3D printed a device to mount in the slot, then ran a USB-C cable through that. Simple plug and play from now one!
I do the 3D design using Autodesk Fusion 360. It's a professional design software tool and is free for hobbyist use.
I use Cura for slicing the 3D models and print them on a Monoprice MP Select Mini v2 printer. It's a great inexpensive printer that I've been using for years.
4x8 Support rails:
Nothing too special here. I just wanted these to look good so I painted the supports to match the bed.
The rear 2x4's are screwed together and tapered at the bottom for a tight fit in the bed. What I've grown to like with these is that they compartmentalize the bed so I can put groceries, etc in the back so they don't fly around everywhere!
