Wood size for Slot

johnparjr

Well-Known Member
First Name
John
Joined
Sep 5, 2020
Messages
262
Reaction score
219
Location
Roseville
Vehicle(s)
2020 Jeep Gladiator Mojave
This might have been covered before but I couldn't find it searching.

What board can you use for the Bed slot and what is the length to cut it if needed to be cut



Advertisement





JohnFinx

Well-Known Member
First Name
Fin
Joined
Jun 12, 2020
Messages
75
Reaction score
142
Location
Lakeland Fl
Website
sites.google.com
Vehicle(s)
2020 Gladiator, 1988 Cherokee , 1969 Plymouth Satellite Conv
Occupation
Telecom engineer
Vehicle Showcase
2
I think I used a 2x6, You will have to measure the length. Make it a little short to make it easy to get in and out, or it will get wedged. Putting a handle somewhere on it to pull it out is helpful. Also you will have to cut the corners off on the bottom to make it fit flat, as the slots are curved there.


Renegade

Well-Known Member
First Name
Zac
Joined
Sep 11, 2017
Messages
2,184
Reaction score
2,515
Location
Signal Mountain, TN
Vehicle(s)
2020 JT
I’m pretty sure it’s two 2x4s (what I use), which are actually 7” total, for a flat load. This is in conjunction with a 2x4 (actually 1.5” wide) across the wheel wells, and tailgate at 1/2 position.


JohnFinx

Well-Known Member
First Name
Fin
Joined
Jun 12, 2020
Messages
75
Reaction score
142
Location
Lakeland Fl
Website
sites.google.com
Vehicle(s)
2020 Gladiator, 1988 Cherokee , 1969 Plymouth Satellite Conv
Occupation
Telecom engineer
Vehicle Showcase
2


I use a trailer for plywood and big stuff, so the handles/tie downs on top don't bother me at all.


TheGreatCO

Well-Known Member
Joined
Jun 10, 2020
Messages
83
Reaction score
68
Location
NJ
Vehicle(s)
Current: 2020 Jeep Gladiator Mojave Previous: 2006 Jeep Wrangler Unlimited, 2013 Ford Escape
I just stuffed the plywood in there and called it a day. No extra wood needed.


Capt.Grumps1075

Active Member
First Name
Stephen
Joined
Oct 15, 2020
Messages
30
Reaction score
17
Location
Lufkin
Vehicle(s)
2020 Gladiator sport s
Occupation
Towboat Captain
I used a 2×8 and screwed a 1×4 on top for a lil lip piece. I forget what the length is though.


Capt.Grumps1075

Active Member
First Name
Stephen
Joined
Oct 15, 2020
Messages
30
Reaction score
17
Location
Lufkin
Vehicle(s)
2020 Gladiator sport s
Occupation
Towboat Captain
I used a 2×8 and screwed a 1×4 on top for a lil lip piece. I forget what the length is though.


firemedic2714

Well-Known Member
First Name
Scotty P
Joined
Oct 24, 2018
Messages
179
Reaction score
154
Location
St. Louis, Missouri
Vehicle(s)
2020 Heep Gladiator Rubicon, 2011 Acura TL SH-AWD, 2015 Honda Civic Si, 1992 Trans Am convertible
Occupation
Firefighter / Paramedic
Vehicle Showcase
1
I used a treated 2x8 cut at just a hair under 57-3/8 in. I cut about 3/4" off the two bottom corners at 45° angles. I have it cut to this length so I can remove and replace it without opening the tailgate and from either side by myself. It also won't vibrate itself out of place while driving. My advice would be to cut it at 57-1/2 in. and shave off a tiny bit at a time until it's to your liking. I hope this helps.
