Soft brake pedal on my Gladiator Rubicon

jc99

Well-Known Member
First Name
jc
Joined
Mar 26, 2019
Threads
7
Messages
104
Reaction score
75
Location
Vancouver
Vehicle(s)
2021 JTRD
Some more info about the brakes on the 2021 JT Rubicon Diesel..... If you have the adaptive cruise control (ACC) give this a test and see what you find. I'd be interested to see what others find.

-set your adaptive cruise control
-well far away from a vehicle Increase the ACC speed so you start to quickly climb in speed
-As you come close to a vehicle in front the ACC will start to brake
-'Carefully' apply your brakes with the pedal, you should find that the pedal is solid and will work very well which is much different then normal. This is due to the ACC already applying the brakes

I say be careful as I found this out when the ACC wasn't braking as fast as I would like and I pressed the brakes hard and went into lockup/ABS immediately on the highway. What I learned from this was you need to be very careful how hard you apply the brakes when ACC is braking, or you need to tap the brakes first to disengage the ACC/ACC braking then the brakes will work a normal (ie mushy).

I feel like there is something wrong with respect to the ACC actuator either air in it or when the brakes are pressed fluid flexes back into the ACC system as well as presses the brakes. I however don't know how in detail the system works. The developer at Jscan (OBD app) told me the JT doesn't have the same type of actuation as the JL so he hasn't added the ABS bleeding procedure as it isn't necessary.

As I stated in the previous post I did do a full system fluid replacement/bleed and cycled the ABS by skidding on gravel to try and make it actuate (not sure if that's really works or not). I felt after the fluid replacement the brakes were a little bit better but still much mushier then I expect/want.
Sponsored



Toyfrog

Well-Known Member
First Name
James
Joined
Sep 4, 2020
Threads
8
Messages
590
Reaction score
672
Location
Houston
Vehicle(s)
2021 Mojave
2021 Mojave and I have the same issue. Buddies 2020 Rubicon with Mopar lift and 35’s feels way better than mine. It will be going to the dealership soon.


Green_Gladiator

Well-Known Member
First Name
Jay
Joined
Jan 23, 2021
Threads
16
Messages
434
Reaction score
755
Location
Daytona FL
Vehicle(s)
21 Mojave, 22 NX350 F-Sport
Occupation
Commercial HVAC
Digging up this older post from a search. I’m experiencing all of the above symptoms on my 21 Mojave. (Gas) If I hit the brakes it feels mushy but if I give them a pump they feel nice and hard. (that’s what she said). Tonight I was at a drive thru and I got the pedal to fade all the way to the floor, but in one pump it was fine. It stops fine, but doesn’t feel like it should. I do, however, remember my JK being this way. I figured it would be better on a new vehicle. I guess not. Anyone get info from a dealer or mechanic?
Hey bud! I have the same issue w/ my gas Mojave ... Curious if you've have it adressed or still experiencing it?


azmojave

Well-Known Member
First Name
Bobby
Joined
Nov 2, 2021
Threads
48
Messages
2,498
Reaction score
5,186
Location
Phoenix, AZ
Vehicle(s)
2021 Sarge Green Mojave
Occupation
Retired Trucker. Current Sawyer
Hey bud! I have the same issue w/ my gas Mojave ... Curious if you've have it adressed or still experiencing it?
Living with it and accepting it as “normal”


Toyfrog

Well-Known Member
First Name
James
Joined
Sep 4, 2020
Threads
8
Messages
590
Reaction score
672
Location
Houston
Vehicle(s)
2021 Mojave
Hey bud! I have the same issue w/ my gas Mojave ... Curious if you've have it adressed or still experiencing it?
Do you know when the trucks with issues were built? My 21 Mojave was built mid January of 2021. My buddies 2020 Rubi doesn’t have the mushy breaks like mine does, just wondering if it may be a brake booster issue from factory?


Sponsored

jc99

Well-Known Member
First Name
jc
Joined
Mar 26, 2019
Threads
7
Messages
104
Reaction score
75
Location
Vancouver
Vehicle(s)
2021 JTRD
Do you know when the trucks with issues were built? My 21 Mojave was built mid January of 2021. My buddies 2020 Rubi doesn’t have the mushy breaks like mine does, just wondering if it may be a brake booster issue from factory?
Any chance you can check the brake booster and master cylinder part number on your buddies that doesn't have the mushy brake pedal?


Toyfrog

Well-Known Member
First Name
James
Joined
Sep 4, 2020
Threads
8
Messages
590
Reaction score
672
Location
Houston
Vehicle(s)
2021 Mojave
Any chance you can check the brake booster and master cylinder part number on your buddies that doesn't have the mushy brake pedal?
I will call him in the morning and see if he can swing by the house and check it out. Damn good idea. 👊🏻


ShadowsPapa

Well-Known Member
First Name
Bill
Joined
Oct 12, 2019
Threads
178
Messages
29,084
Reaction score
34,569
Location
Runnells, Iowa
Vehicle(s)
'22 JTO, '23 JLU, '82 SX4, '73 P. Cardin Javelin
Occupation
Retired auto mechanic, frmr gov't ntwrk security admin
Vehicle Showcase
3
My brakes feel and work fine regardless of ACC mode - braking, not braking, whatever. That tells me some folks are having a problem..........??


Green_Gladiator

Well-Known Member
First Name
Jay
Joined
Jan 23, 2021
Threads
16
Messages
434
Reaction score
755
Location
Daytona FL
Vehicle(s)
21 Mojave, 22 NX350 F-Sport
Occupation
Commercial HVAC
Do you know when the trucks with issues were built? My 21 Mojave was built mid January of 2021. My buddies 2020 Rubi doesn’t have the mushy breaks like mine does, just wondering if it may be a brake booster issue from factory?
Not sure of others .. my build was 3/1/21 ...


CreepyJeepy

Well-Known Member
First Name
Ryan
Joined
Jul 2, 2021
Threads
31
Messages
447
Reaction score
592
Location
Denver
Vehicle(s)
2021 Jeep Gladiator Rubicon 3.0
Occupation
Cyber Security
Diesel here. 21

While the pedal isn’t as hard as my Miata with brembos, stainless, and dot 5.1 they do not fade (and I tow my trailer a lot) and stop as expected. There is also no pedal softness that occurs when auto start is engaged.


Sponsored

OP
OP
CLM

CLM

Active Member
Joined
Jun 21, 2021
Threads
2
Messages
26
Reaction score
31
Location
Georgia, USA
Vehicle(s)
2021 Gladiator Rubicon 3.0 Diesel Sting Gray
Hi, I wanted to give a brief update, I had started this post last July. Sometime last year I spoke to someone at the local dealer, they reminded me that the diesel has no engine vacuum so it's an electric or electronic brake booster. So there's that. He said people complain about them all the time, there's no specific fix, and just live with it. So actually, the brake pedal feel is much better now than it was almost a year ago. I have no idea why that is, but it's fine now and feels like any other truck.


J3colt

Well-Known Member
First Name
John
Joined
Feb 4, 2022
Threads
6
Messages
66
Reaction score
194
Location
Rubicon123!
Vehicle(s)
2008 JKU Rubicon
Not sure of others .. my build was 3/1/21 ...
My JT Rubicon (gas) just passed 1100 miles and I noticed a change in the brake pedal feel as described here. Mine was built 4-2021.

Today was 80 degrees, and I was running the A/C a lot on the highway for the 1st time since buying it. It seems much different and the pedal practically goes to the floor before it stops.


ckgjt

Well-Known Member
Joined
Dec 17, 2019
Threads
2
Messages
131
Reaction score
244
Location
Murrieta Ca
Vehicle(s)
2020 Jeep JT Max ToE
I have the same issue on my 2020. many times the pedal feels like there is a swollen line or some other internal leak as there is no fluid loss. one pump and all is good. I am going to switch to steel braided brake lines and hope that fixes it..if not I will live with it


jnack

Well-Known Member
First Name
Josh
Joined
Apr 25, 2021
Threads
24
Messages
125
Reaction score
33
Location
CA
Vehicle(s)
JTD
I have the same issue on my 2020. many times the pedal feels like there is a swollen line or some other internal leak as there is no fluid loss. one pump and all is good. I am going to switch to steel braided brake lines and hope that fixes it..if not I will live with it
curious if you did this and if any improvement? i have steel braided in rear but not front


ckgjt

Well-Known Member
Joined
Dec 17, 2019
Threads
2
Messages
131
Reaction score
244
Location
Murrieta Ca
Vehicle(s)
2020 Jeep JT Max ToE
curious if you did this and if any improvement? i have steel braided in rear but not front
havent changed them out yet..I unfortunately had a major heart attack and triple bypass not too long after i posted and just recently started driving..still going to be awhile before I can pull my sorry ass up into my Jeep :(
