The alignment pins are probably the best mod I bought for my JK. I kept them hoping they'll fit my JT (if it ever gets here, LOL).On my JK the door bolts and freedom top knobs come out by March and don’t go back until December. I use a small cordless impact driver to take all the bolts on and off. The supplied ratchet handle makes the process a chore.
As for doors on and off the key I’ve found is to roll the windows down and stand to the inside with one hand on the handle and the other on the keeper strap, in the case of the JL/JT I guess it would be reversed, stand to the outside and reach an arm through to the finger hold in the arm rest and the other either on the window frame or the handle.
The bigger hassle is going to be getting them back on, the pins need to be concentric to the pivots on the truck which means if the truck is at some slight angle, the door needs to be at some slight angle as well. For years I’ve debated the extended alignment pins and for years I’ve not actually done it.
Keep the pivots and pins greased with a silicone grease to keep crud and grit out of the holes, grease also helps to control any slack that will develop as they wear against each other. You can get delrin pivot sleeves to rebush them once the clearance gets huge or put them on now and never do it again.
Keep your electrical harness connections clean and greased with dielectric, keeps moisture out which helps control corrosion and makes removal and installation a snap.
