joegrasse

New Member
Joined
Aug 2, 2020
Messages
2
Reaction score
0
Location
Omaha
Vehicle(s)
JLUR
While not specific to the Mojave, I would be interested in the part number for the forward-facing trailcam.



Advertisement





dsgood78

Member
Joined
Aug 7, 2020
Messages
13
Reaction score
4
Location
99206
Vehicle(s)
2020 Jeep Gladiator Overland - North Edition
While not specific to the Mojave, I would be interested in the part number for the forward-facing trailcam.
Agreed, considering it’s an orderable option now for 2021.


Timdog

Well-Known Member
First Name
Tim
Joined
Nov 24, 2019
Messages
149
Reaction score
207
Location
Hamilton
Vehicle(s)
Gladiator JT
Since we have been getting alot of requests for Mojave part numbers we have created this sticky that we will continuously update. Please submit any new requests below in this thread.


Interior
Vent Outlet Left Outer - https://parts.allmoparparts.com/oem-parts/mopar-air-conditioning-and-heater-outlet-6ab641vaac
Vent Outlet Left Inner - https://parts.allmoparparts.com/oem-parts/mopar-air-conditioning-and-heater-outlet-6ab651vaac
Vent Outlet Right Inner - https://parts.allmoparparts.com/oem-parts/mopar-air-conditioning-and-heater-outlet-6ab661vaac
Vent Outlet Right Outer - https://parts.allmoparparts.com/oem-parts/mopar-air-conditioning-and-heater-outlet-6ab671vaac
Steering Wheel - Unpriced 7CG33TX7AA
Steering Wheel Heated - Unpriced 7CG32TX7AA
Automatic Trans. Boot - https://parts.allmoparparts.com/oem-parts/mopar-transmission-shifter-6yl291v5aa
Transfer Case Boot - https://parts.allmoparparts.com/oem-parts/mopar-transfer-case-shift-knob-6wh281v5aa
Instrument Panel Top Pad-
https://parts.allmoparparts.com/oem-parts/mopar-instrument-panel-pad-6ac121v5ac
Center Console Lid - https://parts.allmoparparts.com/oem-parts/mopar-console-armrest-6ac671v5ah
Door Panel Armrest Left Front - https://parts.allmoparparts.com/oem-parts/mopar-front-door-trim-armrest-left-6rl55cv5ad
Door Panel Armrest Right Front - https://parts.allmoparparts.com/oem-parts/mopar-front-door-trim-armrest-right-6rl54cv5ad
Door Panel Armrest Left Rear - TBD
Door Panel Armrest Right Rear - TBD


Exterior
Front Orange Tow Hook https://parts.allmoparparts.com/oem-parts/mopar-tow-hook-68468060aa
Rear Orange Tow Hook
https://parts.allmoparparts.com/oem-parts/mopar-tow-hook-68468059aa
Front Under Bumper Skid Plate - https://parts.allmoparparts.com/oem-parts/mopar-front-skid-plate-68409966aa


Hood Conversion Parts
https://parts.allmoparparts.com/oem-parts/mopar-hood-68338381ac
https://parts.allmoparparts.com/oem-parts/mopar-hood-bezel-68398765ab
https://parts.allmoparparts.com/oem-parts/mopar-hood-insulation-68346961aa
https://parts.allmoparparts.com/oem-parts/mopar-hood-to-fender-mucket-left-68405001ab
https://parts.allmoparparts.com/oem-parts/mopar-hood-to-fender-mucket-right-68405000ab
https://parts.allmoparparts.com/oem-parts/mopar-hood-to-cowl-weatherstrip-68271739ab
https://parts.allmoparparts.com/oem-parts/mopar-hood-seal-68295588ab
X2 https://parts.allmoparparts.com/oem-parts/mopar-fender-to-hood-weatherstrip-68272214aa
X12 https://parts.allmoparparts.com/oem-parts/mopar-mopar-retainer-push-in-6504135
https://parts.allmoparparts.com/oem-parts/mopar-cowl-top-panel-6nt06tzzaa
https://parts.allmoparparts.com/oem-parts/mopar-cowl-side-trim-panel-left-6nt09tzzaa
https://parts.allmoparparts.com/oem-parts/mopar-cowl-side-trim-panel-right-6nt08tzzaa



Suspension & Driveline
Front Shock Left TBD
Front Shock Right https://parts.allmoparparts.com/oem-parts/mopar-suspension-shock-absorber-kit-right-68465846ah
Front Springs TBD
Rear Shock Left https://parts.allmoparparts.com/oem-parts/mopar-suspension-shock-absorber-kit-left-rear-68465832af
Rear Shock Right https://parts.allmoparparts.com/oem-parts/mopar-suspension-shock-absorber-kit-right-rear-68465833af
Rear Spring Left https://parts.allmoparparts.com/oem-parts/mopar-rear-coil-spring-left-68442574aa
Rear Spring Right https://parts.allmoparparts.com/oem-parts/mopar-rear-coil-spring-left-68442575aa
Front Knuckle Left - https://parts.allmoparparts.com/oem-parts/mopar-front-knuckle-left-68477359aa
Front Knuckle Right - https://parts.allmoparparts.com/oem-parts/mopar-front-knuckle-right-68477358aa
Front Upper Control Arm Left - https://parts.allmoparparts.com/oem-parts/mopar-upper-control-arm-left-68461229aa
Front Upper Control Arm Right -
https://parts.allmoparparts.com/oem-parts/mopar-upper-control-arm-right-68461228aa
Track Bar - https://parts.allmoparparts.com/oem-parts/mopar-front-track-bar-left-hand-drive-68496317aa
Jounce Bumpers - TBD




Wheels
Steel Spare Wheel - TBD
Black & Silver Wheel - https://parts.allmoparparts.com/oem-parts/mopar-aluminum-wheel-6pj791xwaa
Black Wheel - https://parts.allmoparparts.com/oem-parts/mopar-aluminum-wheel-6pj78vxwaa
Center Cap for above wheels -
https://parts.allmoparparts.com/oem-parts/mopar-wheel-center-cap-1lb77rxfac


Thank you,
- Benny
Question for you.. does the rubicon & the Mojave use the same floor mats? I was told they fit different in the rear & was wondering if this is true?


remlemasi

Well-Known Member
First Name
Elmer
Joined
Sep 30, 2019
Messages
168
Reaction score
135
Location
SoCal
Vehicle(s)
JTR
Autoweek claims that the Mojave axles are heavier-duty than Rubicon. I think they are wrong, but they actually cite tube thicknesses... Where are they getting their info from?! Perhaps they are comparing to the Sport / Overland axles, not realizing the Max Tow / Rubicon axles are already beefed up and identical to the Mojave?

Can anyone confirm that Autoweek is mistaken?

https://www.autoweek.com/drives/a32...r-mojave-on-the-desert-trails-that-shaped-it/

Under the metal, Mojave has stronger axles with cast-iron steering knuckles up front and thicker tubes in the rear. In fact, the rear axle tubes went from a 6.25mm wall thickness on the Rubicon to 10.5mm on the Mojave to resist fatigue.


Jaxmax

Well-Known Member
First Name
Jack
Joined
Jun 28, 2020
Messages
126
Reaction score
107
Location
Bally, Pa.
Vehicle(s)
Jeep wrangler 2019
Occupation
Electrical Manager
Four wheeler also states that the Mojave has thicker tube walls at 10MM, BUT...also states that both models now share the third generation axles with 10MM tube walls, but the front difference is the Mojave has the cast iron ends versus aluminum on Rubicon, and they go on further to say they both have the same third generation rear axle. I had posted in a Mojave thread about the thicker tube walls, and when questioned by a member pointed to a video of an engineer doing ramp articulation tests between Rubicon and Mojave. Guy was pretty good, he stated Rubicons was 8MM versus Mojave 10MM, Mojave had better artuculation then the Rubicon by a little bit if Ruby sway bar was connected due to Mojave front suspension being an inch higher, but Mojave was blown away when the Ruby disconnect the sway bar. He also said teh Ruby was going to benefit with the thicker walls in future 2021?? I'll look for the video. Why not put the cast iron knuckles on the Ruby also it will be the one to run much larger rock crawling tires then the Mojave? Wouldn't cast iron be same or less then aluminum?

Benny can you tell us if the 2021 Rubicaon and Mojave have the same axle part
number ? Perhaps compare the 2020 part numbers also? Thank you!


remlemasi

Well-Known Member
First Name
Elmer
Joined
Sep 30, 2019
Messages
168
Reaction score
135
Location
SoCal
Vehicle(s)
JTR
Thanks. I agree that it’s confusing and crazy that we don’t have confirmation yet! You’d think that Jeep would highlight the thicker axle tubes on their press materials if it were truly the case as seems like a pretty big deal. Hoping Benny can add some clarity. The fronts will be different for sure as the Rubi has lockers. Rears should be the same.

Regarding the knuckles, I think it has more to do with high-speed impacts. Cast iron is more resilient and can absorb the impacts while aluminum would be more likely to crack. The aluminum is likely plenty strong for slow rock crawling, big tires or not. Just my guess.


Mac

Well-Known Member
Joined
Nov 30, 2017
Messages
126
Reaction score
57
Location
MA
Vehicle(s)
2020 JT Hydro Blue Max Tow
Stopped by a dealer today with two a bunch of brand new Mojave's on the lot. Crawled around them and got the part numbers from the front springs, shocks are massive.

Drivers side front spring 68442569AA
Passenger side front spring 68442579AA


Kev Mojito

Active Member
Joined
Sep 13, 2019
Messages
29
Reaction score
18
Location
Washington
Vehicle(s)
2019 JLUR Mojito
I think the passenger side spring should be 570AA
Jounce Bumper ( bump stop ) 68341367AC

Last edited:

_7slots_

New Member
First Name
Austin
Joined
Aug 27, 2019
Messages
4
Reaction score
4
Location
Arizona
Vehicle(s)
98 ZJ, 2020 JLUR 2.0T [wifes], 2021 JTR Ecodiesel [ordered 7/3]
Occupation
Reactor Operator Trainee
@AllMoparParts.com for the front underbumper skid plate I believe that that the reference number doesn't match the diagram

Also it would appear that #21 and 22 are required to install the skid plate. Would you be able to reference those part numbers?

OP
AllMoparParts.com

AllMoparParts.com

Summit Sponsor (Level 3)
First Name
Benny
Joined
Sep 16, 2019
Messages
251
Reaction score
88
Location
New York
Vehicle(s)
JT's!
  • Thread starter
  • Thread Starter
  • #56
While not specific to the Mojave, I would be interested in the part number for the forward-facing trailcam.

There are multiple parts to the camera and mounting itself which I have linked below. Note in no way are we inferring this is plug and play but I understand there are other threads here discussing what is involved, I would suggest you research them thouroughly.

https://parts.allmoparparts.com/oem-parts/mopar-camera-68436466aa
https://parts.allmoparparts.com/oem-parts/mopar-camera-bracket-68396526ab
x2 https://parts.allmoparparts.com/oem-parts/mopar-screw-68090949aa
x2 https://parts.allmoparparts.com/oem-parts/mopar-push-nut-6510197aa
https://parts.allmoparparts.com/oem-parts/mopar-texture-grille-6qn21rxfab

Please let me know if you have any other questions.
Thanks,
-Benny

OP
AllMoparParts.com

AllMoparParts.com

Summit Sponsor (Level 3)
First Name
Benny
Joined
Sep 16, 2019
Messages
251
Reaction score
88
Location
New York
Vehicle(s)
JT's!
  • Thread starter
  • Thread Starter
  • #57
Question for you.. does the rubicon & the Mojave use the same floor mats? I was told they fit different in the rear & was wondering if this is true?

I dont believe this is true as there is only one part number rear carpet section listed and with a Mojave VIN it shows to use this same one. Same goes for the rubber slush mats.

- Benny

OP
AllMoparParts.com

AllMoparParts.com

Summit Sponsor (Level 3)
First Name
Benny
Joined
Sep 16, 2019
Messages
251
Reaction score
88
Location
New York
Vehicle(s)
JT's!
  • Thread starter
  • Thread Starter
  • #58
Four wheeler also states that the Mojave has thicker tube walls at 10MM, BUT...also states that both models now share the third generation axles with 10MM tube walls, but the front difference is the Mojave has the cast iron ends versus aluminum on Rubicon, and they go on further to say they both have the same third generation rear axle. I had posted in a Mojave thread about the thicker tube walls, and when questioned by a member pointed to a video of an engineer doing ramp articulation tests between Rubicon and Mojave. Guy was pretty good, he stated Rubicons was 8MM versus Mojave 10MM, Mojave had better artuculation then the Rubicon by a little bit if Ruby sway bar was connected due to Mojave front suspension being an inch higher, but Mojave was blown away when the Ruby disconnect the sway bar. He also said teh Ruby was going to benefit with the thicker walls in future 2021?? I'll look for the video. Why not put the cast iron knuckles on the Ruby also it will be the one to run much larger rock crawling tires then the Mojave? Wouldn't cast iron be same or less then aluminum?

Benny can you tell us if the 2021 Rubicaon and Mojave have the same axle part
number ? Perhaps compare the 2020 part numbers also? Thank you!

Here is what I come up with

Front Axle Housing Part #
2020 Mojave 68526133AA
2020 Rubicon 68477136AA

2021 Mojave 68526133AA
2021 Rubicon 68477136AA


-Benny

OP
AllMoparParts.com

AllMoparParts.com

Summit Sponsor (Level 3)
First Name
Benny
Joined
Sep 16, 2019
Messages
251
Reaction score
88
Location
New York
Vehicle(s)
JT's!
  • Thread starter
  • Thread Starter
  • #59
@AllMoparParts.com for the front underbumper skid plate I believe that that the reference number doesn't match the diagram

Also it would appear that #21 and 22 are required to install the skid plate. Would you be able to reference those part numbers?

Correct the 3rd party diagrams are incorrect. I have added the brackets to my post.

Thanks,
- Benny

OP
AllMoparParts.com

AllMoparParts.com

Summit Sponsor (Level 3)
First Name
Benny
Joined
Sep 16, 2019
Messages
251
Reaction score
88
Location
New York
Vehicle(s)
JT's!
  • Thread starter
  • Thread Starter
  • #60
Any idea what is different about the track bar? Is it longer due to the suspension height or stronger somehow?

We do not have the engineering data but based on online data it is unique and described as thicker




- Benny
