Magnuson TVS1900 Kit Available Now
- Thread starter LeftCoast32
- Start date
- Watchers 107
misplacetexan
Well-Known Member
- First Name
- Xavier
- Joined
- Jul 21, 2019
- Threads
- 2
- Messages
- 88
- Reaction score
- 136
- Location
- Baytown, Texas
- Vehicle(s)
- 2020 Jeep Gladiator Billet Silver Sport S/Max Tow Package
- Occupation
- Law enforcement
zy1337
Well-Known Member
- First Name
- Zy
- Joined
- Mar 29, 2021
- Threads
- 15
- Messages
- 171
- Reaction score
- 113
- Location
- california
- Vehicle(s)
- 2021 JT Sport S
Hello, I've read what might be conflicting info that the magnuson supercharger wouldn't work with a manual transmission. Their website doesn't say if it is compatible with MT's like it did for their JK supercharger. Is anyone here running the TVS1900 on an MT JT?
Cheers
Cheers
Sponsored
zy1337
Well-Known Member
- First Name
- Zy
- Joined
- Mar 29, 2021
- Threads
- 15
- Messages
- 171
- Reaction score
- 113
- Location
- california
- Vehicle(s)
- 2021 JT Sport S
Nice, I have been out of the thread for the better part of a year and I'm glad to hear that the MT's are getting some love. While I'm at it, do we have any idea if Magnuson is going to get a CARB EO for 21's? Cheers
DAVECS1
Well-Known Member
- First Name
- David
- Joined
- Jan 24, 2020
- Threads
- 56
- Messages
- 1,861
- Reaction score
- 2,516
- Location
- Peoria, IL
- Vehicle(s)
- 2020 Gladiator Sport S Max Tow
That is a tricky question to answer.
The problem is not all 2021s are tunning the same engine control hardware. To complicate that even further, the ones that are running the same hardware are not running the same control strategy.
Magnuson does have a CARB compliant tune but it is a roll of the dice if it will work on your machine.
The more machines I take on, the more I am having to make custom tweaks with customers and the then find a way to roll that back in so it is a universal file.
It would be cool if Magnuson had the time and the resources to concentrate Jeep platform like I have, but I have my doubts, they have as much data for as many vehicles as I do and that they have spent the time analyzing and testing changes to get them perfected, with diagnostic capabilities, and smooth driveability.
If things keep going the way they are. I may look into CARB. I think I have a shot as I don't disable any emissions equipment, and infact I enable more diagnostic strategies. I also no my fueling is dead on for every situation I have been able to put my jeep into.
To boot my WOT is LEANER than what Jeep does, but still safe as I take advantage of two options built into the software already to cool the cylinder when combustion does not go right, it misfires less and corrects itself faster.
Anyway long story longer, of you have the right 2021 Jeep they jave a CARB compliant tune.
zy1337
Well-Known Member
- First Name
- Zy
- Joined
- Mar 29, 2021
- Threads
- 15
- Messages
- 171
- Reaction score
- 113
- Location
- california
- Vehicle(s)
- 2021 JT Sport S
thanks that's great news, I'll check what PCM I'm running tonight, took delivery of my JT in April 2021 so hopefully everything checks out. Make sure you make a brand new thread if you decide to offer a CARB tune!
zy1337
Well-Known Member
- First Name
- Zy
- Joined
- Mar 29, 2021
- Threads
- 15
- Messages
- 171
- Reaction score
- 113
- Location
- california
- Vehicle(s)
- 2021 JT Sport S
looks like I got the right PCM, that's a good start
hivoltagedriver
New Member
I just stumbled across this thread. A bunch of GREAT info here. I am working on tuning a 2021 (12/20) Gladiator Mohave with the Magnuson SC, and have run into a major issue. I can't read or write a calibration with the RTD flasher utility or with my MPVI2 and HP Tuners. It fails immediately with both. The scanner will connect, but the special functions won't open. The owner has been having some WOT shift issues, so Magnuson sent a new .RTD file but I can't load it. My understanding is that the shop that did the install sent the ECM out to Magnuson to unlock - who sent it to HPT. The ECM has a HPT sticker on it, but it still acts like it's locked. I'm not sure that it ever actually got tuned by the original shop. Any ideas?
I resynced both the RTD adapter and my MPVI2, am running a recent release of HPT, just downloaded the RTD flasher utility from Magnuson.
I resynced both the RTD adapter and my MPVI2, am running a recent release of HPT, just downloaded the RTD flasher utility from Magnuson.
Sponsored
SteveInOrlando
Well-Known Member
- First Name
- Steve
- Joined
- Nov 1, 2020
- Threads
- 21
- Messages
- 507
- Reaction score
- 489
- Location
- Orlando, FL
- Vehicle(s)
- 2021 Jeep Gladiator Sport S
- Occupation
- Software Design
Our trucks only work with the Beta version of the VCM software. I have no idea why the RTD won't connect. Have you reached out to HP Tuners?
DAVECS1
Well-Known Member
- First Name
- David
- Joined
- Jan 24, 2020
- Threads
- 56
- Messages
- 1,861
- Reaction score
- 2,516
- Location
- Peoria, IL
- Vehicle(s)
- 2020 Gladiator Sport S Max Tow
Do you have the security bypass cable installed??
hivoltagedriver
New Member
I do not. I wondered what the other cable was for. Nobody could tell me. Where does that install? I have tuned a bunch of GMs, but Chrysler is a whole different language.
DAVECS1
Well-Known Member
- First Name
- David
- Joined
- Jan 24, 2020
- Threads
- 56
- Messages
- 1,861
- Reaction score
- 2,516
- Location
- Peoria, IL
- Vehicle(s)
- 2020 Gladiator Sport S Max Tow
If you look up under your dash, above the obd connector. There is a black box with two connectors in it. That cable fits into on of those connectors and then plugs back into the box.
hivoltagedriver
New Member
I will try that. Thank you VERY MUCH!
