Short Antennas

Greenterror9

New Member
First Name
Dave
Joined
May 20, 2021
Messages
1
Reaction score
1
Location
Maryland
Vehicle(s)
2021 Gladiator
Bought and returned the Rydonair 7". Reception was horrendous. I like the suggestion of going with the aluminum one, may try that out.





Advertisement



Radio Guy

Well-Known Member
First Name
Mike
Joined
Feb 24, 2021
Messages
107
Reaction score
104
Location
So Cal
Vehicle(s)
2021 Jeep Gladiator Mojave
Occupation
Retired
I bought a 13" rubber job from KSaAuto on Amazon mostly due to their published VSWR plot over the FM band. I deal with a lot of antennas and range testing so this company sounded like they know a little something.

I just ran a test comparing the stock antenna to the 13" with stations in the low, mid and high end of the AM and FM band. On AM a really weak station on the stock antenna just goes away with the 13" on any part of the band. On FM the difference is much less with most weak stations on the stock antenna still there on the 13" but just weaker. In one case at the upper end of the FM band a weak station on the stock antenna was not useable on the 13"

I used to work on car stereos years ago (70s and 80s) and most radios had a tunable capacitor inside to optimize AM reception since the antenna and its interface, cables, etc, are very critical. The capacitor was accessible on the rear panel of the radio or through the cassette door. Years ago I found you could go from a large to small antenna and after peaking the capacitor there was really no difference. Every car stereo installer knew this and when installing a new radio or antenna you had to perform the adjustment.

I'm not up on modern radios and don't know if they still have a user adjustable part to optimize AM reception. Maybe someone can call a dealer and ask. Here is a link to the 13" I bought..
https://www.amazon.com/gp/product/B08CZ5NC4M/ref=ppx_yo_dt_b_asin_title_o04_s00?ie=UTF8&psc=1
