Axle strength and tire size

Delhux

Well-Known Member
Joined
Aug 23, 2019
Threads
43
Messages
569
Reaction score
876
Location
Boston, MA
Vehicle(s)
2020 Gladiator - Overland - Gator
. Main concern is ball joints so I'll be going to CVS and getting some RCV's at some point.
Damn dude, my CVS can barely keep AA batteries in stock. Tell me you’ve got one of those 30% off coupons…
Sponsored



hjdca

Well-Known Member
Joined
Oct 27, 2019
Threads
9
Messages
1,639
Reaction score
2,324
Location
Southern California Mountains
Vehicle(s)
Jeep Gladiator Rubicon manual Sting Gray
Build Thread
Link
Just sitting around and got to thinking. Since these axles on the JT rubicon's and max tow's are supposed be stronger than their predecessors. How big of a tire does one think can be used, daily and also on the trial in tough situations? I know most will use 37" ,which I have and do use and have had no issues with but, lets say maybe 40's, think the axles would hold up?
Weight of each wheel and tire is the big issue.... What ever size you go, if you can keep the weight of each tire and wheel low, this saves the drive train. The easiest thing to do is get as light a wheel as possible. I still would not go over 37", 38" on stock axles.


WXman

Banned
Banned
Joined
Mar 1, 2017
Threads
69
Messages
3,102
Reaction score
4,067
Location
Bluegrass region of Kentucky
Vehicle(s)
2021 Jeep Gladiator Overland EcoDiesel
Occupation
Meteorology and Transportation
So all JT’s get Heavy Duty D44’s. Only the Rubicon, Max Tow, HA, and Mojave get the extra wide axles. Can anyone confirm the non extra wide are not 10mm thick tubes? If so, what does the heavy duty mean in terms of all these axles, regardless of the width?
I'd like to know also, but it'll be impossible to prove unless somebody puts a caliper gauge on both axle tubes inside and out.


WK2JT

Well-Known Member
First Name
Darren
Joined
Mar 11, 2020
Threads
18
Messages
659
Reaction score
664
Location
Denver
Vehicle(s)
JTC
Vehicle Showcase
1
I'd like to know also, but it'll be impossible to prove unless somebody puts a caliper gauge on both axle tubes inside and out.
So on the JL, the extreme recon package calls out the heavy duty D44 as an upgrade. Considering the JL Rubicon front is already a D44 and you can only get the extreme recon package on the Rubicon (the carrier, ring, pinion and width are all the same between JL and JT rubicons), the only thing reasonably left that I can think of is the tube thickness. I don’t believe the heavy duty gets performance ball joints or cromo axles shafts.


CerOf

Well-Known Member
Joined
Jan 1, 2021
Threads
18
Messages
1,377
Reaction score
1,611
Location
Dallas
Vehicle(s)
‘21 JTRD
Just heard synergy replacement ball joints are metal rather than the plastic in the factory; greaseable, too.
That should add some strength.

if you’re easy on the skinny pedal, seems these new D44s will support 37~38s all day long.


Sponsored

ShadowsPapa

Well-Known Member
First Name
Bill
Joined
Oct 12, 2019
Threads
178
Messages
29,081
Reaction score
34,559
Location
Runnells, Iowa
Vehicle(s)
'22 JTO, '23 JLU, '82 SX4, '73 P. Cardin Javelin
Occupation
Retired auto mechanic, frmr gov't ntwrk security admin
Vehicle Showcase
3
Do rubicon and max tow have thicker tube walls than standard D44 or are they just wider with lower gears?

I think D44 axles should be standard on all jl and jt models.
The thicker was debunked as I recall. No one - not a single person - could quote a reliable source proving thicker axle tube walls.

I still have that challenge out there - show the specs, and the tech article showing they are thicker walled axle tubes. It was stated in a very early magazine article as if there was a difference, but others didn't repeat that so I suspect it's being repeated based on an old, likely inaccurate, article.


WXman

Banned
Banned
Joined
Mar 1, 2017
Threads
69
Messages
3,102
Reaction score
4,067
Location
Bluegrass region of Kentucky
Vehicle(s)
2021 Jeep Gladiator Overland EcoDiesel
Occupation
Meteorology and Transportation
The thicker was debunked as I recall. No one - not a single person - could quote a reliable source proving thicker axle tube walls.

I still have that challenge out there - show the specs, and the tech article showing they are thicker walled axle tubes. It was stated in a very early magazine article as if there was a difference, but others didn't repeat that so I suspect it's being repeated based on an old, likely inaccurate, article.
I've seen/heard it in a couple of places. One of them was an interview with an engineer when the JT launched two years or more ago now. Unfortunately, finding that link today would be like trying to find a needle in a haystack. But apparently it is true, the axle tube thickness increased to handle the additional payloads and trailering weights they were targeting with JT design.

The part that has been so confusing is the difference between the standard and "wide-track" axles. A list of differences between the two that's 100% accurate has been impossible to find. There have been rumors of higher spline count axle shafts in the wide-tracks, thicker axle tubes only on the wide-tracks, larger ring gears, etc. Nothing has been shown with proof.

The only thing we know for a fact is that certain parts of the axles were made smaller to acquire higher MPG for CAFE scores. So we ended up with weaker parts so that Jeep could save 0.002 MPG on a highway cycle test.


shrinkhead

Well-Known Member
Joined
Dec 21, 2019
Threads
62
Messages
748
Reaction score
711
Location
Massachusetts
Vehicle(s)
Gladiator Launch Edition
I'm running 38's on stock Rubicon. Main concern is ball joints so I'll be going to CVS and getting some RCV's at some point. 2nd most concern is FAD. Going to truss it. 3rd concern is rear axle shaft. Will go to chromoly. At that point it will be time to put on some 40's.
Have you done any of this yet ? Since I bought a Rubicon I want to get as much mileage as possible out of the “heavy duty D44s”. I have the RCVs go in the front tomorrow and the Yukons for the rear “if they ever show up”. I am close to thinking to cancel them and just put D60 in for the rear but don’t really want to for reason mentioned (not for $$& sake). Currently 37s and 40s next summer when the tires arrive lol

  • Like
Reactions: Mac

Rummie

Well-Known Member
First Name
Troy
Joined
May 25, 2019
Threads
80
Messages
660
Reaction score
1,364
Location
Siesta Key, Florida
Website
www.siestakeyrum.com
Vehicle(s)
20 JT, 15 JKU, 22 BMW 4, Challenger R/T
Build Thread
Link
Occupation
Rum
Vehicle Showcase
3
I'm on 37s but do run it pretty hard on occasion. I went with Artec trusses/gussets, chromoly rear shafts, and RCVs up front. I run heavy Nitto Trail Grapplers (not a fan of light tires with thinner sidewalls). So far no problems. I would go D60s if I went to 40s. I know some are running 40s on the trails with D44s, but it seems more likely to leave you stranded at some point.


Sponsored

DankjeeP

Well-Known Member
First Name
Keith
Joined
Jan 13, 2021
Threads
24
Messages
771
Reaction score
868
Location
USA
Vehicle(s)
'21 JTR, '98 XJ, '17 FLHXS
Build Thread
Link
Occupation
HW Engineer
I'm on 37s but do run it pretty hard on occasion. I went with Artec trusses/gussets, chromoly rear shafts, and RCVs up front. I run heavy Nitto Trail Grapplers (not a fan of light tires with thinner sidewalls). So far no problems. I would go D60s if I went to 40s. I know some are running 40s on the trails with D44s, but it seems more likely to leave you stranded at some point.
I too run 37's but Milestar, RCV's and Spicer ball joints. Chromoly rear shafts still in the box lol. Took them along to Moab, but need to install still. So many other things going on. Anyway, things held up just fine. I would not run 40's on these D44 personally.


Troybilt

Well-Known Member
First Name
Troy
Joined
Jun 1, 2016
Threads
69
Messages
2,093
Reaction score
3,589
Location
Ohio
Website
troynemitz.smugmug.com
Vehicle(s)
2020 JTR
Occupation
Parks Operations
Have you done any of this yet ? Since I bought a Rubicon I want to get as much mileage as possible out of the “heavy duty D44s”. I have the RCVs go in the front tomorrow and the Yukons for the rear “if they ever show up”. I am close to thinking to cancel them and just put D60 in for the rear but don’t really want to for reason mentioned (not for $$& sake). Currently 37s and 40s next summer when the tires arrive lol
I have not. it will be awhile as my seasonal work is drying up and my furnace just took a dump:crying:
